Description | Required Specification |
Tunnel size | 653*505mm (W*H) |
Conveyor speed | 0.20m/s, bi-direction scan |
Conveyor height | 693mm |
Max Load | 170kgs |
Wire Resolution | 30AWG Standard, 40A WG |
Typical | |
Spatial resolution | Vertical: diameter 1.0mm, |
Horizontal: diameter 1.0mm | |
Steel Penetration | 34mm steel panel |
Monitor | 21.5 inch,High Resolution |
1280*1024 | |
X Ray generator | 160KV (working at 150 KV) |
anode voltage | |
Explosive and | Separately show 3 different |
Narcotics | levels to accurate mark |
suspicious: | |
Z7 | |
Z8 | |
Z9 | |
Alarm | High Density Alarm |
Atonic Number | Saved image can show atonic |
number of different material | |
Cooling/operation | Oil Cooling /100% |
cycle | |
Image processing | Color/black & white image, |
Negative Image, High | |
Penetration, Low Penetration, | |
Super-enhancement, histogram | |
equalization, check | |
back/forward, Automatic save | |
image, Pseudo color, 90-degree | |
rotation images, Organic/in- | |
organic stripping | |
Zoom | Variable zoom up to 64X, |
support continuous | |
magnification. | |
Image Checking | Continuous check back image |
Storage capacity | Can store more than 100,000 |
